The same model, attempt 2: a clean 7.3m build.	Attempt 1: 7.9m — then block 13 brings it all down. It rebuilds to 4.0m from the rubble.

An LLM benchmark: build the tallest tower you can by placing blocks through a small SDK — under a position/velocity uncertainty contract. You can place a block precisely, or control its velocity precisely, but not both:

sigmaX * sigmaV = K        (constant per challenge)

focus = 1   -> exact position, wild velocity (block may kick sideways at spawn)
focus = 0   -> exact velocity, wild position (block may appear off-target)
focus = 0.5 -> balanced      (sigmaX = sigmaX0, sigmaV = sigmaV0)

The requested velocity is the mean of the sampled velocity, so allocating some focus to velocity lets an agent "press" a block gently into place instead of gambling on a sideways kick — the trade-off is the benchmark's core skill.

Physics is simulated headlessly (rapier3d, deterministic with a seeded RNG). three.js is a viewer only — replays re-simulate from (challengeId, seed, placement log) with the same core code the scorer used.

Quickstart

npm install
npm test                              # unit + determinism + scoring tests
npm run agent:naive -- --challenge bricks --seed 1   # scripted baseline, writes replays/
npm run dev                           # viewer -> http://localhost:5173/src/viewer/

The viewer loads ?replay=/replays/<file>.json (defaults to the naive baseline run). Play/pause, speed, and a scrub slider are at the bottom.

Running LLM agents

npm run bench -- --model claude-fable-5 --challenge bricks --seeds 3x11
npm run bench -- --model gpt-5.6-sol  --challenge mixed --seeds 11,12,13

--seeds 3x11 = three attempts on seed 11 (same seed across attempts measures in-context improvement); --seeds 11,12,13 = one attempt per seed. Models starting with claude use the Anthropic API (ANTHROPIC_API_KEY / ANTHROPIC_API_KEY_PERSONAL); everything else uses OpenAI-compatible chat completions (OPENAI_API_KEY, --base-url for other providers).

--mode episodic (default) starts each attempt with a fresh conversation: when an attempt ends the model distills what it learned into a persistent notebook (update_notebook), the context resets, and the next attempt begins with only the system prompt, the harness-kept history table, and that notebook — so the live context stays ~10–15k tokens no matter how many attempts. --mode session is the original single-conversation behavior, kept for comparison.

Provider knobs (env): BENCH_HTTP_TIMEOUT_MS (per-request timeout, default 300000) and BENCH_MAX_TOKENS (cap completion length) — both default off/unset and exist for slow or non-terminating reasoning models (e.g. k3, whose server can otherwise generate past every timeout on long planning turns).

scripts/coverage.sh runs a model × challenge coverage matrix in parallel lanes (one concurrent run per model) — edit the lane lists to taste.

Per run the harness writes: one replay per attempt (viewable in the viewer), a run-<label>-<challenge>-<runId>.json score summary (including mode and notebook entries), and a full transcript-*.json of every turn. Attempts auto-advance when the inventory is exhausted; the model can also abandon early via next_episode.

Layout

src/core/    authoritative headless sim (no DOM): physics, uncertainty, scoring
  types.ts       shared interfaces (blocks, placement API, challenges, replay)
  sim.ts         rapier world wrapper: step, settle detection, contact queries
  uncertainty.ts focus -> sigmas (sigmaX * sigmaV = K), Gaussian sampling
  episode.ts     validation -> sample -> simulate-to-settle -> replay log
  scoring.ts     tower height via contact chain to the ground
  challenges.ts  10 challenges: bricks, bricks50, bricks100, bricks50k2, bricks50k4, mixed, sparse, storm, pillars, slick
src/sdk/     what an agent (LLM or scripted) drives
  tools.ts       tool schemas (get_inventory / observe / place_block) + SDK_DOC
  utils.ts       spatial helpers (rotatedExtents, stackCenterY, footprint, ...)
  client.ts      EpisodeClient: typed wrapper + callTool dispatch
src/viewer/  three.js replay viewer (re-simulates replays, scrub playback)
src/agents/  naive.ts — scripted baseline agent, writes replays/*.json
tests/       vitest: rng, uncertainty contract, episode validation, determinism, scoring

Placement API (summary)

place_block({
  blockId: 'b1',
  position: [0, 0.31, 0],   // desired center, meters, y-up
  yawDeg: 90,               // optional, default 0
  orientation: 'upright',   // optional named pose: box flat|side|upright, cylinder upright|flat
  quat: [0, 0, 0.7071, 0.7071], // optional full-resolution rotation (precedence over orientation/yaw)
  velocity: [0, -0.3, 0],   // optional desired MEAN velocity, |v| <= maxSpeed
  focus: 0.6,               // required: precision allocation, [0, 1]
})
// -> { ok, actual: { position, velocity, sigma: {x, v} },
//      settle: { outcome, tower, spawnOverlap, spawnPenetration, ... } }
// or { ok: false, error } — validation errors are retryable and free

Score = max top-y over blocks with a contact chain to the ground, after the whole inventory settles. Peak height is tracked separately. Blocks that fall off the ground plane are lost. Spawning inside another block is not an error — physics resolves it (violently); the result reports spawnOverlap.

Leaderboard

http://localhost:5173/src/board/ lists every attempt (sortable, filterable by challenge and group) with watch links into the viewer. It reads replays/index.json, regenerated automatically after every run or via npm run board. Tag related runs with --group <name> to compare them as a set.

Status

Working: core sim, 10 challenges, SDK + spatial utilities, naive baseline agent, replay viewer, LLM harness (episodic + session modes), leaderboard board. Full model × challenge coverage matrix lives in replays/ (group cov-1); known tuning knobs (settle thresholds, per-challenge K) are listed as open decisions in the project plan.

License

MIT — see LICENSE.

A math vs vibes project.
